XCMG XGT6515-10S Flat-Top Tower Crane – Professional Overview

The XCMG XGT6515-10S is a flagship model in XCMG’s S-series of flat-top tower cranes. It is an ideal solution for medium-to-large scale construction projects, renowned for its exceptional lifting capacity, extensive operational adaptability, advanced intelligence, and superior energy efficiency.

1. Core Performance & Advantages

• Powerful Load Handling: Boasts a rated load moment of 160 t·m, a leading figure in its class, ensuring robust foundational lifting capabilities.

• Versatility in Load & Reach:

  • A maximum lifting capacity of 10 t at a working radius of 14.8m, ideal for heavy-load, short-distance lifting.

  • A maximum jib length of 65m provides extensive coverage, with a tip load of 1.5 t for efficient handling of lighter loads at long distances.

• Flexible Jib Configuration: The jib can be configured in 8 different lengths from 30m to 65m in 5m increments, allowing for precise adaptation to various project structures and construction phases.

2. Working Height & Enhanced Capabilities

• High Free-Standing Height: A maximum free-standing height of 60m meets the requirements for many mid-rise buildings without the need for tie-ins, simplifying initial construction.

• High Tied-In Height: With a tie-in system, the maximum working height can be extended up to 267.2m, making it capable of tackling super-tall building construction.

• XCMG Super-Lift System: Features XCMG’s exclusive super-lift technology, which enhances the rated load moment by 8%-16%, significantly expanding its heavy-load handling capabilities.

3. Key Mechanism Features

• Hoisting Mechanism:

  • Efficient & Intelligent: A maximum hoisting speed of 90 m/min, coupled with an “Auto-Speed Matching” function that automatically adjusts speed based on load, ensuring both safety with heavy loads and efficiency with light ones.

  • Large Rope Capacity: A hoisting rope capacity of 503-615m meets the demands of ultra-high construction.

  • Powerful Motor: Driven by a 37kW high-efficiency motor, suitable for high-frequency operation.

• Trolleying (Traversing) Mechanism:

  • Smooth & Precise: Trolleying speed is variable from 0-58 m/min with frequency control, ensuring smooth movement and accurate positioning with minimal load swing.

  • Energy Efficient: Powered by a low-consumption 4kW motor.

• Slewing (Rotation) Mechanism:

  • Stable & Controlled: Slewing speed of 0-0.7 r/min with multi-stage closed-loop control for exceptionally smooth starts and stops, minimizing structural shock.

  • Dual-Motor Drive: Utilizes 2 x 5.5kW motors, providing ample torque for stable rotation even under wind or off-center loads.

4. Comprehensive Economy

• Optimized Energy Consumption: The total installed power (excluding the climbing system) is only 52kW, demonstrating excellent energy efficiency optimized for long-duration operation, which helps reduce overall operating costs.

In Summary:

The XCMG XGT6515-10S is a star product that combines high performance, great adaptability, advanced control, and outstanding economy. From its core lifting parameters down to the details of its mechanism control, it embodies XCMG’s profound technical expertise and deep understanding of customer needs, making it a reliable partner for modern, efficient construction.
